Sykes’ AFPK1543 is a robust medium-sized 6” electric submersible wastewater pump suitable for commercial, industrial and utility applications. This particular model comes in either a 14kW or a 16kW version and delivers maximum flows of up to 110 litres per second. Capable of operating on a guide rail or freestanding, the AFPK1543 can operate at heads of 31 metres and features motor temperature sensors to ensure the pump always functions at full capacity.
Key Features
- Contrabloc Impeller providesblockage-free operation
- Double mechanical sealsfor maximum abrasive resistance
- Premium Efficiency IE3 motorfor reduce energy consumption
- Simple design allows minimalservice and maintenance
- Easily portableso can be positioned quickly
- Motor protection reducesthe risk of damage
- Flexible configuration suitablefor both wet & dry installations
- No vibration allows smoothrunning and constant flows
Environments
- Building and construction
- Emergency
- Municipal treatment sites
- Wastewater pumping networks
- Sewage
- Manufacturing and industry
- Industrial processes
- Commercial drainage
- Food preparation processes
- Agriculture
- Utility industries
Accessories
- 22KW SOFT START STARTER
- 6" X 3M W/A BAUER HOSE
- 6" 20FT W/A SUCTION HOSE BAUER
- 6" 20FT POLYTUBE
- 6" X 6M HELIFLEX PVC BAUER
- 6" X 6MTR STEEL BAUER PIPE
- 6" 45* BAUER BEND
- 6" 90* BEND
- 6" GATEVALVE
- 6" NON-RETURN VALVE
- ROAD RAMP C/W 6" PN16 FLANGES
- ROAD RAMP WIDE C/W 6" PN16 FLANGES
- ROAD CROSSING C/W 8" PN16 FLANGES
Specifications
- Motor type
- 415V (3-Phase) 50Hz
- Motor rating
- 16kW
- Running current
- 32A
- Running speed
- 1450 rpm
- Discharge port
- 150mm
- Suction inlet port
- 150mm
- Maximum solids
- 100mm
- EX Rated
- Yes/No
- Cooling jacket
- Yes/No
- Dimensions (H x W)
- Guide rail option
- 1155 x 585mm
- Weight
- 340kg
- Transportable option
- 1325 x 998mm
- Weight
- 370kg
