  • Features / Environments
  • Specifications
  • Accessories
Features
  • Quiet operation – enabling use within built-up areas
  • Automatic thermostat – for accurate temperature control
  • IP65 rated electrics – can be used outside
  • Compact unit – can be used in restricted areas
  • Energy efficient – 30kW of cooling from a 32-amp power supply
  • Air recirculation – increases efficiency by using the returned air rather than outside air
  • Easy installation – for quick set-up
  • Wheel-mounted chassis – simplifying manoeuvrability
Environments
  • Data rooms
  • Storerooms
  • Server rooms
  • Temporary accommodation
  • Workshops
  • Open plan areas
  • Marquees and events
  • TV and film studios
  • Hospitality units
  • Film sets
Nominal cooling duty
30kW
Plug type
BS4343 32 A 5 Pin
Air flow (max)
5,900m3/h
Average power consumption
6.8 kW/h
Typical cooled area
666m3
Duct length (max)
16 metres
Power supply
415 v 3 ph N+E RUN 22 A
Duct diameter size
450 mm
Noise level (max)
64 dBA @ 3 metres
Dimensions (L x W x H)
1,600 x 730 x 1,660 mm
Weight (kg)
435 kg
Control
Automatic thermostat
(Capable of operating down to 10°C)
  • 300MM x 8M HEATING DUCTING WITH CLAMP
  • 10M EXT LEAD 5 PIN 32AMP 415V 6MM DIA
  • 20M EXT LEAD 5 PIN 32AMP 415V 6MM DIA
