Features
  • Compact unit – can be used in restricted areas
  • Low temperature capability – down to as low as -5 ̊C
  • Quiet operation – low noise level of 70 dBA @ 10 metres
  • Economical – reducing running costs
  • Fast connecting line couplings – for simple and fast installation
  • Provides both heating and cooling – for all year-round use
  • Fully portable – can be positioned more easily
  • Robust construction – will stand up to the rigours of industrial use
Environments
  • Food and beverages
  • Building and construction
  • Petrochemicals and refineries
  • Manufacturing and industry
  • Emergency chillers
  • Events and corporate hospitality
  • Pharmaceuticals
  • Computer and sever rooms
  • Process cooling
  • Agriculture
Nominal cooling duty
50 kW 170,500 btu
Power supply
415 V 3 ph N+E 50 Hz Run 50.4 A
Plug type
BS4343 63 A 5 pin
Noise level (max)
70 dBA @ 10 metres
Weight
1,210kg
Dimensions (L x W x H)
2,380 x 1,170 x 2,340 mm
Control
Automatic programmer
Average power consumption
15.6 kW/h
Generator size
60 kVA
Water Connection
50mm (2”) Bauer
Nominal water flow
2.3 l/s
  • 10M x 5 PIN 63 AMP 415V EXTENSION LEAD 25MM DIA
  • 20M x 5 PIN 63 AMP 415V EXTENSION LEAD 25MM DIA
  • 50mm (2”) BORE HOSE PER WATER (BAUER CONNECTION)
  • FAN COILS/ AHU’S
  • MANIFOLDS
  • SYSTEM CONNECTION FITTINGS
  • PLATE HEAT EXCHANGER
